Metra Electronics 99-5814 - Stacked ISO Mount Units Installation

99-5814
7
1. Cut and remove the center bar from the
radio housing. (Figure A)
2. Snap the Double DIN brackets to the
inside edge of the radio housing.
(Figure B)
3. Slide the stacked ISO mount units into
the bracket/housing assembly and
secure the units to the assembly using
the screws supplied with the units.
(Figure C)
4. Snap the Double DIN trim plate onto the
front of the radio/housing assembly.
(Figure C)
Reassemble dash in reverse order of
disassembly.
Stacked ISO Mount Units Provision
(Figure A)
(Figure B)
(Figure C)
