2
99-5814
4. Remove the (2) 7 MM screws exposed
at the bottom of the factory radio panel.
(Figure D)
5. Slide radio out and remove (1) 8mm bolt
from the right side securing the ground
strap to the radio brackets. Unplug and
remove the radio.
6. Remove (4) Torx screws securing the
climate controls to the factory radio
panel. Remove the climate controls and
retain them with the factory screws for
use during kit assembly. (Figure E)
Continue to kit assembly
Dash Disassembly
All Vehicles
(Figure A)
REAR CLIMATE CONTROL
REAR OF RADIO
(Figure B)
To Next Page
