Metra Electronics 99-5814 - Dash Disassembly Procedure

1. Unclip and remove the a/c vent panel
above the radio. (Figure A)
2. Remove the (2) 7 MM screws exposed
at the top of the factory radio panel.
(Figure B)
3. Unclip the accessory socket/switch/aux
input panel below the radio. Unplug
and remove the panel. (Figure C)
Continue on page 2
1
Dash Disassembly
All Vehicles
(Figure A)
99-5814
(Figure B)
(Figure C)
