2
99-5815 DASH DISASSEMBLY
A
B
C
D
E
FORD MUSTANG 2005-2009
Remove the small rectangular shifter
lever trim panel if equipped
.
(Figure A)
2
Remove (4) 9/32” screws from the
radio to remove.
(Figure E)
7
Remove (2) Phillips screws from under
the center armrest at the back of the
shifter trim panel (including cup
holders).
(Figure B)
3
Unclip and remove panel.
(Figure B)4
Unclip and remove the (2) center
stack trim panels from the left and
right side of the radio and climate
controls.
(Figure C)
5
Remove (6) 9/32” screws from cen-
ter trim panel surrounding the radio
and climate controls then unclip and
remove panel.
(Figure D)
6
Continue to final assembly.
*
Note: Refer also to the instructions included with the aftermarket radio.
Disconnect the negative battery termi-
nal to prevent an accidental short cir-
cuit.
1
