99-5815 DASH DISASSEMBLY
A
B
C
D
E
FORD FIVE-HUNDRED 2005-2007/FORD TAURUS 2008-09
MERCURY MONTEGO 2005-2007, MERCURY SABLE 2008-09
Unclip and remove the small rectan-
gular trim around shift lever.
(Figure A)
2
Unclip and remove the entire panel
(including cup holders) surrounding the
shift lever.
(Figure B)
3
Remove (2) 9/32” screws at the bottom
of the center radio/climate control
panel.
(Figure C)
4
Remove (4) 9/32” screws from the
radio to remove.
(Figure E)
6
Unclip and remove the center panel.
(Figure D)
5
Continue to final assembly.
*
Note: Refer also to the instructions included with the aftermarket radio.
Disconnect the negative battery termi-
nal to prevent an accidental short cir-
cuit.
1
