1. Unclip and remove the trim panel along
the top of the glove box over to the
passenger side a/c vent. (Figure A)
2.
Unclip and remove the small trim panel to
the left of the hazard button. (Figure A)
3. Remove (2) Phillips screws securing the
climate/radio panel, then unclip, unplug
and remove the panel. (Figure B)
Note: A climate extension harness is
provided to extend this harness lower
in the center console where the climate
will be relocated to.
4.
Remove (4) Phillips screws securing the
radio chassis. Slide the chassis out, then
unplug and remove the chassis. (Figure C)
Note: The white 4-pin harness will be
reused in Kit Assembly. (Figure D)
Continued on the next page
DASH DISASSEMBLY
(Figure A)
(Figure C) (Figure D)
(Figure B)
