KIT PREPARATION
1. Attach the console bracket to the back
of the A/C button housing using (4) of
the provided #8 x 3/8” Phillips screws.
(Figure A)
2. Install the (2) metal panel clips saved
from the pocket disassembly onto the
console bracket . (Figure A)
3. Using the climate extension harness
provided, connect the A/C button
housing assembly to the factory wiring
harness in the vehicle.
4. Secure the A/C button housing into the
pocket space in the front of the center
console. (Figure B)
Continue to Kit Assembly
(Figure A) (Figure B)
