Metra Electronics 99-7519B - Page 4

Carefully remove the side panels
from each side of the radio/climate
control panel by pulling straight back
towards the rear of the car.
(Figure G)
8
G
99-7519B
DASH DISASSEMBLY
MAZDA MX-5 MIATA 2009-2010
6
Unclip, unplug and remove the entire
center console. (Figure E)
7
Remove the (2) Phillips screws
securing the side panels from each
side of the radio/climate control
panel. (Figure F)
E
F
2
