99-7519B
DASH DISASSEMBLY
Remove (2) Phillips screws, (1) on
each side, from the side of the
radio/climate control panel.
(Figure H)
9
Pull radio/climate control panel out,
disconnect plugs and remove.
(Figure I)
10
MAZDA MX-5 MIATA 2009-2010
Turn the radio/climate control panel
over and remove the (4) screws that
hold the climate control to the bezel,
then remove the climate control.
(Figure J)
11
H
I
J
3
