Metra Electronics 99-7524B - Kit Preparation; Electronic climate control

99-7524B
5
Kit Preparation
Electronic climate control
1. Clip the climate control knob outer trim ring panel
into the 99-7524B housing. (Figure A)
2. Align the screw holes in the climate control and the
radio housing panel then push the climate control
onto the radio housing panel. (Figure B)
3. Secure the climate control with the factory
hardware removed in step 7 of the dash
disassembly for electronic climate control cars.
4. Unclip and remove the small oval cover plate at the
bottom center of the factory radio and insert into
the 99-7524B radio housing. (Figure C)
5. Attach (6) panel clips supplied to the radio
housing.
Note: The light bulb boards will not be used with
auto climate control vehicles disregard these bulbs.
(Figure B)
REAR VIEW OF ELECTRONIC CLIMATE CONTROL
(Figure A)
(Figure C)
