99-7867 KIT ASSEMBLY
DIN RADIO PROVISION
Slide the DIN cage into the radio hous-
ing and secure by bending the metal
locking tabs outward. (Figure A)
1
Slide the aftermarket radio into the
cage until it snaps into place. (Figure A)
2
Continue to final assembly.
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Mount the ISO brackets to the radio
using the screws supplied with the
radio.
(Figure A)
1
Slide the radio into the radio housing
until the ISO brackets snap into place.
(Figure A)
2
Snap the trim plate onto the front of
the radio housing. (Figure A)
3
A
A
ISO RADIO PROVISION
