1. Unclip and remove the (2) small trim
panels from the top of the center
console next to the cigarette lighter
pocket. (Figure A)
2. Rotate the a/c vents down so they are
facing the floor, release the (4) tabs
inside the top edge of the panel, then
unclip and remove the a/c vents from
the dash. (Figure B, C)
3. Remove (4) 10mm bolts securing the
factory radio/climate control assembly,
then unplug all harnesses and remove
the assembly. (Figure D)
4. Behind the radio/climate control panel
is a module. This module will need
to be relocated to allow room for the
aftermarket radio.
Continue to Kit Preparation
(Figure B) (Figure D)
(Figure A) (Figure C)
DASH DISASSEMBLY
