MD9272 Leakage Clamp TRMS Meter with Power Function Instrument Description
8
LCD Screen
Data retention indication.
Maximum reading indication.
Minimum reading indication.
Peak measurement function, this is the maximum value of the
measured magnitude, whether voltage or current.
Phase angle measurement function of the current in reference to
the voltage.
Indicates that the current is in front compared to the voltage.
Indicates that the current is behind compared to the voltage.
Indication of a loss, possibly due to insulation defects, only in the
mA measurement mode.
Indication of a loss, possibly due to insulation defects and
accumulation of non-lineal loads, only in the mA measurement
mode.
Indication of a loss, possibly due to a high accumulation of non-
lineal loads, only in the mA measurement mode.
Indication that the measured magnitude is expressed in a true
effective value.
Measurement function of the crest factor of the measured
magnitude.
