Metso LCP9H Series Installation, Maintenance And Operating Instruction

Metso Flow Control Inc.
Europe, Vanha Porvoontie 229, P.O. Box 304, FI-01301 Vantaa, Finland. Tel. +358 20 483 150. Fax +358 20 483 151
North America, 44 Bowditch Drive, P.O. Box 8044, Shrewsbury, M A 01545, USA. Tel. +1 508 852 0200. Fax +1 508 852 8172
South America, Av. Independéncia, 2500-Iporanga, 18087-101, Sorocaba-São Paulo, Brazil. Tel. +55 15 2102 9700. Fax +55 15 2102 9748
Asia Pacic, Haw Par Centre #06-01, 180 Clemenceau Avenue, Singapore 239922. Tel. +65 6511 1011. Fax +65 6250 0830
China, 11/F, China Youth Plaza, No.19 North Rd of East 3rd Ring Rd, Chaoyang District, Beijing 100020, China. Tel. +86 10 6566 6600. Fax +86 10 6566 2583.
Middle East, Roundabout 8, Unit AB-07, P.O. Box 17175, Jebel Ali Freezone, Dubai, United Arab Emirates. Tel. +971 4 883 6974. Fax +971 4 883 6836
www.metso.com/valves
12
11 TYPE CODING
OPTIONAL DEVICE FOR VG9000H
LCP9H_
Local Control Panel (LCP)
Versions for Ex ia/ic/nL: LCP9H, LCP9HW. Stainless steel 316L, IP66.
Versions for Ex d: LCP9HE, LCP9HEW. Anodized aluminum, IP66
All versions include LEDs, Manual Reset and PST buttons.
Trip button removed in W versions. Buttons are lockable in all versions.
Power consumption 400 mW. Power supply 11-30 V DC, 50 mA
ATEX and IECEx certifications:
LCP9H, LCP9HW:
II 2 G Ex ia IIC T6...T4 Gb
Ui ≤ 25.2 V, Ii ≤ 150 mA, Pi ≤ 650 mW, Ci ≤ 30 nF, Li ≤ 252 μH.
Temperature range: T4; -20° to +65 °C, T5; -20° to +65 °C, T6; -20° to +50 °C.
II 3 G Ex ic IIC T6...T4 Gc
Ui ≤ 25.2 V, Ii ≤ 150 mA, Pi ≤ 650 mW, Ci ≤ 25 nF, Li ≤ 201 μH.
Temperature range: T4; -20° to +65 °C, T5; -20° to +65 °C, T6; -20° to +60 °C.
LCP9HE, LCP9HEW:
II 2 GD
Ex d IIB+H
2
T6 Gb
Ex tb IIIC T85°C Db IP65
Ta -20° to +55 °C
Ui ≤ 25.2 V, Ii ≤ 50 mA, Pi ≤ 1.26 W.
Equipped with sunshade to comply with higher anb. temp. requirements
INMETRO certifications:
LCP9H, LCP9HW:
Ex ia IIC T6...T4 Gb
Tamb: T6; -20 ... +50 °C, T5; -20 ... +65 °C, T4; -20 ... +65 °C
Ui: 25.2 V, Ii: 150 mA, Pi: 650 mW, Ci: 30 nF, Li: 252 μH
Uo: 9.8 V, Io: 47 mA, Po: 120 mW, Co: 3.3 μF, Lo: 252 mH
Ex ic IIC T6...T4 Gc
Tamb: T6; -20 ... +60 °C, T5; -20 ... +65 °C, T4; -20 ... +65 °C
Ui: 25.2 V, Ii: 150 mA, Pi: 650 mW, Ci: 25 nF, Li: 201 μH
Uo: 8.8 V, Io: 42 mA, Po: 93 mW, Co: 45 μF, Lo: 45 mH
LCP9HE, LCP9HEW:
Ex d IIB+H
2
T6 Gb
Ex tb IIIC T85°C Db IP65
Ta -20° to +55 °C
Ui ≤ 25.2 V, Ii ≤ 50 mA, Pi ≤ 1.26 W.
NOTE: 7. sign "L2" in VG9000H type coding needs to be selected for additional conduit entries
and terminal strip in VG9000H.
NOTE: See manual 7VG9H70en for further VG9000H details.
