5
Material and weight
LCP9H,
LCP9HW 316L stainless steel, 2.8 kg
LCP9HE,
LCP9HEW Copper-free aluminium alloy with
epoxy coating, 14.6 kg
Dimensions
LCP9H and LCP9HW
With buttons and cable glands (approx.):
270 mm x 200 mm x 137 mm (h x w x d)
LCP9HE and LCP9HEW
With buttons and sunshade:
413 mm x 412 mm x 252 mm (h x w x d)
APPROVALS
Intrinsically safe
IECEx Ex ia IIC T6...T4 Gb
Ex ic IIC T6...T4 Gc
IEC 60079-0: 2011
IEC 60079-11: 2011
ATEX II 2G Ex ia IIC T6...T4 Gb
II 3G Ex ic IIC T6...T4 Gc
EN 60079-0: 2012, EN 60079-11: 2012
INMETRO
Ex ia IIC T6...T4 Gb
Ex ic IIC T6...T4 Gc
ABNT NBR IEC 60079-0:2013
ABNT NBR IEC 60079-11:2009
Flameproof and explosion proof
IECEx Ex d IIB+H
2
T6 Gb
Ex tb IIIC T85 °C Db IP65
IEC 60079-0: 2007, IEC 60079-1: 2007,
IEC 60079-31: 2008
ATEX II 2GD
Ex d IIB + H2 T6 Gb
Ex tb IIIC T85°C Db IP655
EN 60079-0: 2009-10, EN 60079-1: 2007-04,
EN 60079-31: 2009
INMETRO
Ex d IIB+H2 T6 Gb
Ex tb IIIC T85 °C Db IP65
ABNT NBR IEC 60079-0:2008 versão corrigida 2011
ABNT NBR IEC 60079-1:2009 versão corrigida 2011
ABNT NBR IEC 60079-31:2011
ABNT NBR IEC 60529:2009
Electromagnetic protection
Electromagnetic compatibility
Emission acc. to EN 61000-6-4: 2007
Immunity acc. to EN 61000-6-2: 2005
1.6 Recycling and disposal
Most local control panel parts can be recycled if sorted
according to material. Most parts have material marking. In
addition, separate recycling and disposal instructions are
available from the manufacturer.
The Local Control Panel may also be returned to the manufac-
turer for recycling and disposal. There will be a charge for this.
1.7 Safety precautions
2 TRANSPORTATION, RECEPTION AND
STORAGE
The Local Control Panel is a sophisticated instrument, han-
dle it with care.
 Check the Local Control Panel for any damage that
may have occurred during transportation.
 Store the Local Control Panel preferably indoors and
keep it away from rain and dust.
3 MOUNTING
3.1 Electrical connections
There are two terminal blocks located in the circuit board
inside the LCP9H (see Fig. 4). LOOP terminals are for connec-
tion to the VG9000H and PWR terminals are for the 24 V DC
power supply.
CAUTION:
Do not exceed the permitted values!
Exceeding the permitted values may cause damage to
the local control panel and to equipment attached to
the panel.
Damage to the equipment and personal injury may
result.
CAUTION:
During maintenance or commissioning when the
device cover is open, ensure that water does not go
inside the enclosure.
CAUTION:
Do not operate the device with the cover open or
removed!
Electromagnetic immunity is reduced.
Ex d WARNING:
Do not open the cover when an explosive atmosphere
may be present!
Ex d and Ex tb WARNING:
Use a cable gland with suitable Ex d IIC and Ex tb IIIC certi-
fication. Use cable gland suitable for at least
-20 °C to 70 °C.
Ex d NOTE:
Only persons familiar with Ex d explosion protection are
allowed to work with the device. Special attention has to
be paid to careful handling and closing of the cover.
NOTE:
Avoid earthing a welding machine in close proximity to
the LCP9H.
Damage to the equipment may result.
NOTE:
The enclosure of the LCP9H meets the IP66 protection
class according to EN 60529 in any position when the
cable entries are plugged according to IP66.
Based on good mounting practice, the recommended
mounting position is with electrical connections placed
downwards. If these requirements are not met, and the
cable glands are leaking and the leakage is damaging the
LCP9H electronics, our warranty is not valid.
