Fill/dump only: Indicates the acceptable
amount of material that might remain in the
intermediate container for IND360 to consider it
empty – for example, material stuck to the
sides of a hopper.
[0 – Capacity]
+ Tolerance sets the maximum permissible
amount above the target weight.
[0 – Capacity]
- Tolerance sets the minimum permissible
amount below the target weight.
[-Capacity - +Tolerance]
Defines the upper limit for the automatic refill to
stop. The refill signal will stay high until the
upper limit is reached.
[0 – Capacity]
If a Dose is started and the material in the tank
weighs less than Lower Limit, the refill signal
will be triggered and stays high until the weight
of material in the tank reaches the Upper Limit.
[Target – UpperLimitWeightConfig]
Container Tare Max sets the maximum weight
of an empty container. Used when auto tare
function is enabled. The empty container needs
to be in this range for the fill operation to be
started.
[-Capacity – Capacity]
Container Tare Min sets the minimum weight of
an empty container. Used when auto tare
function is enabled. The empty container needs
to be in this range for the fill operation to be
started.
[-Capacity – ContainerTareMaxConfig]
Inhibit Time sets the amount of time that the
comparator will have to wait before it is
allowed to compare. This is used to ignore
peaks in the weight signal when turning on
feeds or switching between feed speeds.
[0 – 9.99s]
Optional parameter. Stability Timeout is the
maximum length of time the program will wait
for a stable weight reading after material
dispensing has stopped. A value of 0 disables
the timeout and will allow the IND360 to wait
indefinitely for stability.
[0 – 9.99s]
Fill/Dump mode only, when complete mode is
set to “Time mode”. Complete Time sets a fixed
duration for the dump process to be executed.
[0 – 9.99s]
