750-LFC OPERATING INSTRUCTIONS
32
750-LFC cabinets need not be equipped with the MRK-750
rigging kit for transport with the caster frame. The
loudspeaker skids ensure that cabinets stack cleanly on the
caster frame. However, to avoid tipping, straps (not included)
should be used when transporting cabinets that have not
been fitted with the MRK-750 rigging kit.
750-LFC cabinets equipped with the MRK-750 rigging kit
provide for more secure transport, because the bottom
cabinet can be linked and pinned to the caster frame. The
three cabinets can be linked and pinned together as well.
TIP: Durable nylon pullover covers, sized for
stacks of 2 units or 3 units, are available to
protect 750-LFC cabinets during transport.
Special wraparound covers are also available to
accommodate stacks with grids on top.
TIP: The MG-MINA/LINA/750-LFC grid can
travel installed on top of 750-LFC stacks on the
MCF-750 caster frame.
Figure 27: MCF-750 Caster Frame, (3) 750-LFCs (without Rigging),
using straps (Not Included)
Figure 28: MCF-750 Caster Frame, (3) 750-LFCs (with Rigging)
