CHAPTER 4: QUICKFLY RIGGING
35
DIMENSIONS: MCF-750 CASTER FRAME WITHOUT RIGGING
MCF-750 Caster Frame without Rigging Weight: 28.7 lbs (13.0 kg)
Figure 30: MCF-750 Caster Frame Dimensions (for cabinets without rigging)
24.16 in
[614 mm]
24.91 in
[633 mm]
17.14 in
[435 mm]
7.50 in
[190 mm]
5.85 in
[149 mm]
17.70 in
[450 mm]
