APPENDIX A: CAL SPECIFICATIONS
38
AUDIO / CONTROL
Analog Audio (3) Phoenix 6-pin male connectors for balanced audio input and loop output
Digital Audio (1) Phoenix 6-pin male connector for AES/EBU input
Note: The connector’s bottom three pins are not used.
Ethernet and AVB AVB-enabled Ethernet ports for integrated audio streaming, beam control and RMS monitoring via
Compass control software. Supports communication of AVB timing data and audio signals via AAF packets
(AVTP Audio Format) and communication of AVB clock signals via CRF packets (Clock Reference Format).
Processing Mute, gain, 5-band parametric EQ, and delay, stored in four onboard presets
Note: Processing and beam settings can be edited in Compass control software and saved in four onboard
presets.
Logic I/O Phoenix 6-pin male connector, recalls onboard presets, reports relay closures (and openings) for fault
reports; Phoenix 5-pin male connector, triggers emergency mute and input override
Display OLED button displays the CAL loudspeaker's network addresses during startup or when the button is
pushed
AC POWER
Connector powerCON 20
Rated Voltage Range 100–240 V AC, 50–60 Hz
Turn-on and Turn-off Points 90 V AC turn-on; 264 V AC turn-off
CURRENT DRAW
Idle CAL 96 1.98 A rms (115 V AC) 1.63 A rms (230 V AC) 2.32 A rms (100 V AC)
CAL 64 1.24 A rms (115 V AC) 0.99 A rms (230 V AC) 1.42 A rms (100 V AC)
CAL 32 0.58 A rms (115 V AC) 0.45 A rms (230 V AC) 0.65 A rms (100 V AC)
Maximum Long-Term
Continuous (>10 sec)
CAL 96 8.3 A rms (115 V AC) 4.2 A rms (230 V AC) 9.4 A rms (100 V AC)
CAL 64 6.1 A rms (115 V AC) 3.1 A rms (230 V AC) 6.9 A rms (100 V AC)
CAL 32 3.3 A rms (115 V AC) 1.7 A rms (230 V AC) 3.7 A rms (100 V AC)
Burst (<1 sec) CAL 96 14.7 A rms (115 V AC) 7.3 A rms (230 V AC) 18.5 A rms (100 V AC)
CAL 64 10.8 A rms (115 V AC) 5.4 A rms (230 V AC) 13.6 A rms (100 V AC)
CAL 32 5.9 A rms (115 V AC) 2.9 A rms (230 V AC) 7.4 A rms (100 V AC)
Maximum Instantaneous
Peak
CAL 96 33 A peak (115 V AC) 18 A peak (230 V AC) 40 A peak (100 V AC)
CAL 64 24 A peak (115 V AC) 13 A peak (230 V AC) 29 A peak (100 V AC)
CAL 32 13 A peak (115 V AC) 7 A peak (230 V AC) 16 A peak (100 V AC)
