-39-
PARTS BREAKDOWN
ITEM E-58H, E-78 & E-88 QTY DESCRIPTION
1 15869 1 Pump & Motor Assy. (12 volt)
2 15727 1 • Motor - 12 Volt (2 Terminal)
3 15889 1 • Pump Assy.
4 15874 1 ••Kit - Pump Relief Valve
5 15870 1 •• Relief Valve Assy.
6 15878 1 •• Plug w/O-Ring
7* 15875 1 Seal Kit Relief Valve
8 15877 1 Pump Shaft Seal
9 22339 3 Soc. Head 5/16-18 x 1-3/4”
10 15204 1 Cylinder Tank
11* 15131 1 O-Ring 3-1/2 I.D.
12* 15163 1 O-Ring 1-15/16 I.D.
13* 15198 1 O-Ring 1-1/8 I.D.
14 15738 1 Cover & Seal Assy.
15* 05119 1 • Wiper
16* 15131 1 • O-Ring 3-1/2 I.D.
17 15737 1 • Sleeve
08473 1 Pressure Relief Valve Kit
18 21805 1 • Reducer Bushing 1/4 x 1/8
19 21806 1 • Pressure Relief Valve
20 15205 1 Cylinder
21 15209 1 Washer (Grooves Down)
22 15761 1 Ram Assembly
23 15206 1 • Ram
24 15158 1 • Piston
25 15219 1 • Piston Follower
26 15760 1 • Spacer
27* 15162 1 • Packing Cup
28* 15125 1 • O-Ring 7/16 I.D.
29 20316 1 • Locknut 1/2-13
30 15980 1 Base & Strainer Assy.
31 15326 1 • Strainer
32 15641 1 • Filter Kit - 9/16”
33 15619 1 •• Filter
34 21999 1 •• Plug w/O-Ring - 9/16”
35 15203 3 Stud
36 15621 1 Baffle
37 21980 2 Retainer Ring
38 15574 1 Pump Check Valve Kit
39* 15124 1 • O-Ring 3/8 I.D.
40 15354 1 • Seat
41 15603 1 • Ball, 9/32
42 15604 1 • Spring
43* 15122 3 O-Ring 1/4 I.D.
44 21999 2 Drain Plug w/O-Ring - 9/16”
45* 15127 1 O-Ring 5/8 I.D.
46* 21929 3 Washer, Nyltite 5/16
47 20697 3 Locknut 5/16 - 24
ITEM E-58H & E-78 E-88 QTY DESCRIPTION
48 15612 15941 1 • Valve Assy. w/Coup. (12V)
49 --------- 22445 2 • Coupler, Female Half
49 22445 --------- 1 • Coupler, Female Half
50 --------- 22442 2 • Coupler, Male Half
50 22442 --------- 1 • Coupler, Male Half
51 --------- 15925 2 “A” & “B” Solenoid Assembly
51 15925 --------- 1 “A” Solenoid Assembly
52 15916 15916 1 •• Coil (12V)
53 15917 15917 1 •• “A” & “B” Cartridge Valve
54 15928 15928 1 ••• Seal Kit, “A” & “B” Valve
55 15926 --------- 1 “B” Solenoid Assembly
56 15916 --------- 1 •• Coil (12V)
57 15918 --------- 1 •• “B” Cartridge Valve
58 15929 --------- 1 ••• Seal Kit, “B” Valve
59 15959 15952 1 • Kit- “B” Check Valve
60 15986 --------- 1 • “B” Check Valve Nut
61 15982 --------- 1 • O-ring
62 15939 15939 1 •• O-ring
63 15945 15945 1 •• “B” Valve Check Body
64 15947 15947 1 •• O-ring
65 15946 15946 1 •• “B” Valve Check Poppet
66 15935 15935 1 •• Spring
67 --------- 15926 2 “C” & “D” Solenoid Assembly
68 --------- 15916 1 •• Coil (12V)
69 --------- 15918 1 •• “C” & “D” Cartridge Valve
70 --------- 15929 1 ••• Seal Kit “C” & “D” Cartridge
71 15987 --------- 2 “C” Solenoid Assembly
72 15916 --------- 1 •• Coil (12V)
73 15958 --------- 1 •• “C” Cartridge Valve
74 15930 --------- 1 ••• Seal Kit “C” Cartridge
75 --------- 15927 1 “E” Solenoid Assembly
76 --------- 15916 1 •• Coil (12V)
77 --------- 15919 1 •• “E” Cartridge Valve
78 --------- 15930 1 ••• Seal Kit “E” Cartridge
79 15950 15950 1 Kit Needle Valve (Lower Adj.)
80 15942 15942 1 • O-ring
81 15933 15933 1 • Needle Valve
82 15948 15948 1 • Needle Valve Retaining Ring
83 15934 15934 1 • Nut M6 x 1/2” nut
84 --------- 15949 2 • Kit Dual PO Check Valve
85 15965 --------- 1 • Kit Dual PO Check Valve
86 --------- 15944 2 •• Check Valve Assembly
87 15944 --------- 2 •• Check Valve Assembly
88 15943 15943 1 •• P.O. Pilot Spool
89 15999 --------- 1 •• Spring
90 15951 15951 1 Kit P.A. Block Filter
91 15936 15936 1 • Tank Filter
92 15938 15938 1 • O-ring
93 15937 15937 1 • M16 x 1 Filter Cap
94 15974 15974 1 • Kit-Crossover Valve
95 1 •• O-ring
96 1 •• O-ring
97 1 •• Body
98 1 •• O-ring w/Glyd. Ring
99 1 •• Poppet
100 1 •• Washer
101 1 •• Spring
102 1 •• Plug
* 15975 15975 1 •• Seal Kit-Crossover Valve
(includes items 83,84,86)
103 21826 21826 4 Soc. Head 5/16-18 x 1-1/2”
Parts indented are included in assembly under which they are indented.
*Parts included in Master Seal Kit Part No. 15969 (E-58H & E-78),
15978 (E-88)
Basic Seal Kit Part No. 15254
Pump Relief Valve @ 2000 + 50 P.S.I. full flow. Non Adjustable
Crossover Relief Valve @ 3800 ± 400 P.S.I. @ 2-1/2 G.P.M. Non Adjustable
