-33-
PARTS BREAKDOWN
E-46, E-47 & E-47H
E-57 & E-57H
ELECTRO-LIFT
®
Parts indented are included in assembly under which they are indented.
15865 15866 1 Lift Ass'y. (Unit only) 12 volt
15881 15885 1 Lift Ass'y. (Unit only) 24 volt
1 15869 15869 1 Pump & Motor Assy. (12 volt)
1b 15890 15890 1 Pump & Motor Assy. (24 volt)
2a 15727 15727 1 • Motor - 12 Volt (2 Terminal)
2b 15891 15891 1 • Motor - 24 Volt (2 Terminal)
3 15889 15889 1 • Pump Assy.
4 15874 15874 1 ••Kit - Pump Relief Valve
5 15870 15870 1 •• Relief Valve Assy.
6 15878 15878 1 •• Plug w/O-Ring
7* 15875 15875 1 Seal Kit Relief Valve
8 15877 15877 1 Pump Shaft Seal
9 22339 22339 3 Soc. Head 5/16-18 x 1-3/4"
10 15045 15204 1 Cylinder Tank
11* 15131 15131 1 O-Ring 3-1/2 I.D.
12* 15163 15163 1 O-Ring 1-15/16 I.D.
13* 15198 15198 1 O-Ring 1-1/8 I.D.
14 15194 15194 1 Cover & Seal Assy.
15* 05119 05119 1 • Wiper
16* 15131 15131 1 • O-Ring 3-1/2 I.D.
17 15199 15199 1 • Sleeve
08473 08473 1 Pressure Relief Valve Kit
18 21805 21805 1 • Reducer Bushing 1/4 x 1/8
19 21806 21806 1 • Pressure Relief Valve
20 15207 15205 1 Cylinder
21 15209 15209 1 Washer (Grooves Down)
22 15335 15761 1 Ram Assembly
23 15208 15206 1 • Ram
24 15158 15158 1 • Piston
25 15219 15219 1 • Piston Follower
26 15760 15760 1 • Spacer
27* 15162 15162 1 • Packing Cup
28* 15125 15125 1 • O-Ring 7/16 I.D.
29 20316 20316 1 • Locknut 1/2-13
30 15573 15573 1 Base & Strainer Assy.
31 15326 15326 1 • Strainer
32 15641 15641 2 • Filter Kit - 9/16"
33 15619 15619 1 •• Filter
34 21999 21999 1 •• Plug w/O-Ring - 9/16"
35 15042 15203 3 Stud
36 15621 15621 1 Baffle
37 21980 21980 2 Retainer Ring
38 15574 15574 1 Pump Check Valve Kit
39* 15124 15124 1 • O-Ring 3/8 I.D.
40 1 • Seat
41 1 • Ball, 9/32
42 1 • Spring
43* 15122 15122 3 O-Ring 1/4 I.D.
44 21999 21999 1 Drain Plug w/O-Ring - 9/16"
45* 15127 15127 1 O-Ring 5/8 I.D.
46* 21929 21929 3 Washer, Nyltite 5/16
47 20697 20697 3 Locknut 5/16 - 24
48 15972 15972 1 "A" Solenoid Assembly
49 15905 15905 1 •• "A" Coil, Black Wire (12V)
50 15660 15660 1 •• "A" Cartridge Valve
51* 15431 15431 1 ••• Seal Kit, "A" Valve
48b 15661 15661 1 "A" Solenoid Assembly
49b 15659 15659 1 •• "A" Coil, Black Wire Plastic
15662 15662 1 •• "A" Coil, Black Wire (24V)
50a 15660 15660 1 •• "A" Cartridge Valve
51b* 15431 15431 1 ••• Seal Kit, "A" Valve
52 15758 15758 1 • Valve Assy. w/Coup. (12V)
15779 15779 1 • Valve Assy. w/Coup. (24V)
53 22295 22295 1 • Forged 90 Degree Elbow
54 22294 22294 1 • Coupler, Female Half
55 22293 22293 1 • Coupler, Male Half
56 15639 15639 1 • Kit-Pilot Check Valve
57 1 •• Ball, Steel
58 1 •• Spring
59 1 •• Plug
60 15609 15609 1 • Piston
61 15359 15359 1 • Plug Valve Block
62* 15126 15126 1 •• O-ring 9/16 I.D.
63 15697 15697 1 • "B" Solenoid Assembly
64 15382 15382 1 •• "B" Coil, Red Wire
15444 15444 1 •• "B" Coil, Red Wire (24V)
65 15698 15698 1 •• "B" Cartridge Valve
66* 15432 15432 1 •• Seal Kit-"B" Cartridge
67 15576 15576 1 • Kit- "B" Check Valve
68 1 •• Ball, 7/16
69 1 •• Spring
70 15358 15358 1 • "C" Solenoid Assembly
71 15430 15430 1 •• "C" Coil, Green Wire
15445 15445 1 •• "C" Coil, Green Wire (24V)
72 15381 15381 1 •• "C"-Cartridge Valve
73* 15433 15433 1 •• Seal Kit-"C" Cartridge
74 15606 15606 1 • Kit-Crossover Valve
* 15610 15610 1 •• Seal Kit-Crossover Valve
(includes items A,B,D,M)
75 21826 21826 4 Soc. Head 5/16-18 x 1-1/2"
PARTS LIST
STANDARD- LONG STROKE-
UP THROUGH HM-9 & HM-10
C-9 ONLY
ITEM 1-1/8" x 6" Stroke 1-1/8" x 8" Stroke QTY. DESCRIPTION
E-57 E-57H
STANDARD- LONG STROKE-
UP THROUGH HM-9 & HM-10
C-9 ONLY
ITEM 1-1/8" x 6" Stroke 1-1/8" x 8" Stroke QTY. DESCRIPTION
E-57 E-57H
* Parts included in Master Seal Kit Part No. 15888
Basic Seal Kit Part No. 15254
Pump Relief Valve @ 2000 P.S.I. full flow. Non Adjustable
Set Crossover Relief Valve @ 3800 ± 400 P.S.I. @ 2-1/2 G.P.M.
