Meyer Manufacturing Corporation - 80 - PB-MIXER-TR-MECH
OPTIONAL EQUIPMENT
HAY RETAINING RING
KEY PART NUMBER QTY DESCRIPTION MIXER MODEL
1 M4-1-5-0001 2 Hay Retention Ring End Weldment 585
M4-1-7-0001 2 Hay Retention Ring End Weldment 700
2 M4-1-7-0002 2 Hay Retention Ring Side Weldment 585/700
NS 851-5013-1.25Z AR 1/2”-13 x 1-1/4” Bolt 585/700
NS 805-0050-Z AR 1/2” Flat Washer 585/700
NS 810-5013-Z AR 1/2” Spin Lock Nut 585/700
