Meyer Formula - Dual Slide Tray Hydraulic Schematic

1-800-325-9103
PB-MIXER-TR-MECH - 85 - www.meyermfg.com
DUAL SLIDE TRAY HYDRAULIC SCHEMATIC
KEY PART NUMBER QTY DESCRIPTION MIXER MODEL
1 155-6801-6-8 2 90 Degree Adapter 585/700
2 155-2-8-1.125-1 2 2” x 8” x 1-1/8” Hydraulic Cylinder 585/700
3 155-04R17-59-1 2 1/4” x 59” Hose Assembly 585/700
4 155-04R17-144-1 2 1/4” x 144” Hose Assembly 585/700
5 155-6400-6-8 2 Straight Adapter 585/700
6 155-M-0002 1 Cylinder Valve Bank 585/700
7 155-04R17-70-1 2 1/4” x 70” Hose Assembly 585/700
8 155-2603-06-06-06 2 Tee Connector 585/700
9 155-6500-06-06 2 90 Degree Connector 585/700
(5,:1((5*
)5217/()76/,'(
75$<&</,1(5
<$57(',/6
1:2'
<$57(',/6
38
+&678('//$761,
+7,:*8/3
.&,76<2-025)
</%0(66$66(15$+
+&678('/
/$761,
+7,:*8/3
.&,76<2-025)
</%0(66$66(15$+
(',/67)(/5$(5
5('1,/<&<$57
(5,:(8/%
6
1
5
4
3
2
7
8
9
