MFJ MFJ-993 - Figure 10. Main Mode Menus Display

MFJ-993 IntelliTuner Automatic Antenna Tuner Instruction Manual
© 2003-2004 MFJ Enterprises, Inc.
12
Frequency
Indicators: Antenna, Memory, IntelliTune
Indicators: Auto/Semi, StickyTune
SWR
Forward power in watts
Reflected power in watts
Indicators: SWR Beep, LC Limit, Meter Range
Forward power bar meter
Reflected power bar meter
Forward power in watts
SWR bar meter
Antenna symbol (antenna side of L-network)
Inductance value
Capacitance value when on antenna side
Capacitance value when on transmitter side
Appears when Antenna 1 is selected
Appears when Antenna 2 is selected
Appears when Memory is ON
Appears when IntelliTune is ON
Appears when in Semi-Auto mode
Appears when StickyTune is ON
Appears when LC Limit is OFF
Appears when SWR Beep is ON
Appears when Meter Range is 300 watts
Appears when Auto Range is ON
25
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
21
20
22 23
24
25
16
18 19
17
18 19
Enlarged Views of Indicators
2 2
3 7
1 2 3 4
5 6 7
10
8
9
1 2 3 4
7
11
1 2
3
4
7
12 13
14
15
2 3 4
7
Figure 10. Main Mode Menus Display.
