2. Key to symbols
Guarantee
The function and safety of the equipment is only
guaranteed if the warning and safety instructions
included in these operating instructions are adhered
to.
MFZ Antriebe GmbH + Co.KG is not liable for any
personal injury or damage to property that occurs as
a result of the warning and safety instructions being
disregarded.
Using the equipment for its intended purpose
The CS 300 controls are designed only for controlling
gates and doors with digital end position systems.
It is only permitted to operate the equipment in dry
rooms.
Target group
Only qualifi ed and trained electricians may connect,
programme and service the controls.
Qualifi ed and trained electricians meet the following
requirements:
- knowledge of the general and specifi c safety and
accident prevention regulations,
- knowledge of the relevant electrical regulations,
- trained in the use and care of appropriate safety
equipment,
- capable of recognising the dangers associated with
electricity.
Instructions for installation and connection
- The controls must be disconnected from the
electricity supply before carrying out electrical
works. It must be ensured that the electricity supply
remains disconnected during the works.
- Local protective regulations must be complied with.
- Mains cables and control cables must be laid
separately.
Danger of personal injury!Danger of personal injury!
The safety instructions must be
observed!
Warning! Danger to property! Warning! Danger to property!
The safety instructions must be
observed!
InformationInformation
Reference to other sources of
information.
1. Contents 2
2. Key to symbols 2
3. General safety instructions 2
4. Overview of products 3
5. Initial Operation 5
6. Programming with the LED module 8
7. Programming with the LCD monitor 10
8. Navigator (LCD monitor only) 12
9. Overview of functions 14
10. Error messages and rectifi cation 18
11. Technical data 19
12. EU Declaration of Conformity 19
