Electrical
Press the
arm
down
onto
the spindle until 'it is retained in position by the clip.
Fig. 12 Ensure
that
there is a distance between the top wiper blade pivot (1)
and
the
windscreen rubber (2) in the position shown as follows:
'A'-Left-hand
arm
t to 1 in.
'B'-Centre
and
right-hand
arm
--§-
to
tin.
WINDSCREEN
WIPER
AND
WASHER
Wiper
arms
To re-position a wiper
arm
on the spindle, hold the spring clip (1) clear of the
Fig. 13 retaining groove in the spindle and withdraw the arm. Position the
arm
on the
spindle (2).
Windscreen
'The windscreen washer system should be checked for borrect operation and the
' w asher reservoir refilled if necessary every week
and
before a long journey in addi tion to
Fig. 14 the mileage intervalsgiven in
'MAINTENANCE
SUMMARY'.
Washer reservoir. To fill the reservoir (2), remove the cap (1) and lift the reserv ir
from its mounting.
In cold weather the washer reservoir should be filled with a mixture of water and
a recommended washer solvent to prevent the water freezing.
On no account should radiator anti-freeze or methylated spirits (denatured
alcohol) be used in the windscreen washer.
Jet
adjusting.
Turn
the jet (3) using a small screwdriver to adjust the height of the
spray. The spray should strike the top of the windscreen.
Wiper
blade
To renew a wiper blade pull the
arm
away from the windscreen.
Hold
the fastener
Fig. 13 (3)
and
the spring retainer (4) away from the wiper
arm
(5)
and
withdraw the
blade assembly from the arm.
Insert the end of the wiper arm into the spring fastener of the new blade
and
push
the blade into engagement
(6) with the arm.
To ensure efficient wipingit is recommended that wiper
blades
are renewed annually.
Fig. 13
Part No.
BHA
5382
GLB 380
GLB 380
BFS 273
BFS 254
GLB 382
BFS 501
GLB 281
GLB 281
GLB 281
GLB 281
GLB 280
GLB 987
,BFS 643
GLB 254
GLB 254
GLB
281
'GLB 281
GLB
281
Watts
60/50
5/21
5/21
18
6
21
5
2
2
2
2
1·5
2'2
2·2
6
6
2
2
2
Volts
12
12
1
12
112
12
12
12
112
112
12
.12
12
12
12
12
12
12
112
12
Replacement
Headlamp-sealed
beam
bulbs
Sidelamp (with flasher) . .
Stop/tail
..
Reverse
Number-plate lamp
Direction indicator
Side marker lamp, front and rear
Ignition warning
..
Main beam
Direction indicator warning lamp
Oil pressure warning lamp
Brake warning lamp
Panel illumination lamp
Cigar-lighter illumination
Luggage compartment lamp
Courtesy lamp
Seat belt warning lamp
..
Switch illumination
Heater
rotary
control illumination
Fig. 12
Fig. 14
3N
240
Fig. 12
Fig. 14
