Figure EPS 6000 Controls and Indicators
2-4
Figure
EPS 6000 Front Panel
2-5
Note: The SSC does not include inverter on or inverter off pushbuttons #6 and #7,
or the battery operation LED #4.
Circuit breakers
and switches
behind
cabinet
door
Front
panel
Hidden
panel
Cover
Alphanumeric
display
2 — 4 Operation
EPS 6000 UPS Shared Systems
