SECTIONS 9 10 11 12 13 14 15 16
No. DESCRIPTION
1 CONTROL PANEL 1249109
2 GASKET 61 x 48 x 3 8566000
3 REDUCING BUSH 1”1/2 x 3/4 8588806
4 THERMOSTAT POCKET 1764200
5 RIGHT CAST IRON CLEANING
ACCESS COVER PLATE 0633700
5 LEFT CAST IRON CLEANING
ACCESS COVER PLATE 0633800
6 CERAMIC FIBRE PANEL FOR ITEM 5 0666700
7 CAST IRON CLEANING
ACCESS COVER PLATE 0633600
8 CERAMIC FIBRE PANEL FOR ITEM 7 0666600
9 CONNECTION PIECE 8589402
10 GAS VALVE ROBERTSHAW 0656002
11 ELBOW PIPE 0653310
12 GAS DISTRIBUTION PIPE 0654100
13 CAST IRON FRONT PLATE 0633200
14 CERAMIC FIBRE FRONT PANEL 1266001
15 FIXING BRACKET 0648600
16 FRONT GAS BURNER 1255210 1255210 1255212 1255212 1255214 1255214 1255216 1255216
REAR GAS BURNER 1255209 1255210 1255210 1255212 1255212 1255214 1255214 1255216
17 PILOT BURNER BRAHMA BPEMC70 0660101
18 BLIND PLUG 1/2” 8589604
19 REDUCING BUSH 1" 1/2x1/2 8588801
20 FRONT SECTION 1230000
21 RIGHT SUPPORT FOOT 0634304
21 LEFT SUPPORT FOOT 0634305
22 PIPE-FIXING BRACKET 0648000
23 GAS FEED PIPE 1251509 1251510 1251511 1251512 1251513 1251514 1251515 1251516
24 INTERMEDIATE SECTION 1230500
25 TIE RODS M14 (SET) 2384009 2384010 2384011 2384012 2384013 2384014 2384015 2384016
26 RIGHT SUPPORT FOOT 0634304
26 LEFT SUPPORT FOOT 0634305
27 DISTRIBUTION PIPE 0651501
28 REAR SECTION 1230900
29 RUBBER GASKET 155x105x70 2366200
30 FLANGE 2" 1/2 8591853
31 REAR CAST IRON PLATE 0633200
32 REAR CERAMIC FIBRE PANEL 1266001
33 REAR CAST IRON CLEANING
ACCESS COVER PLATE 0633900
34 REAR CER. FIBRE PANEL FOR ITEM 33 0666800
36 FLUE HOOD 1246159 1246160 1246161 1246162 1246163 12460164 1246165 1246166
37 DRAUGHT DIVERTER 1246059 1246060 1246061 1246062 1246063 1246064 1246065 1246066
38 THERMOSTAT POCKET 8564200
39 ELBOW PIPE 1251500
40 FRONT/REAR APRON 1245101
41 SIDE PANELS FIXING BRACKET 1245151
42 MOTOR BRACKET 1248050
44 JOINT 1277000
45 DAMPER MOTOR 1272559
6
