DMX512 LED Transmier Control
DMX512
Control Panel
Connect
DMX512 Transmier
2.4GHz Wireless Signal
Zone
1
Limitless
Limitless
16
Zone
8.8.8.8
+
SET
-
(Purchased separately)
DMX512 LED Transmier Link/Unlink
If the link or unlink failed, please follow the above steps again.
Link/Unlink buon
Link
Unlink
Follow instrucon of DMX512 transmier (FUTD01), Choose the zone for the light by pressing
“ + ” or “ - ” (e.g. “CH12” means zone 12)
1
Power
The controller is powered off for
10 seconds and then powered on,
or press “ SET ” buon 1 me.
The controller is powered off for
10 seconds and then powered on,
or press “ SET ” buon 1 me.
2 3
Power
4
Link is done once
indicator of controller
flashes 3 mes slowly
Short press “ ” 3 mes
within 3 seconds while the
indicator of controller is ON
+
SET
-
SET
SET
Short press “ ” 5 mes
within 3 seconds while the
indicator of controller is ON
SET
Unlink is done once
indicator of controller
flashes 10 mes quickly
⸺ 11 ⸺
