Index
No.
Swaco
Part No.
Description Qty.
76 65-92-328 Terminal Wire 1/0 AWG Ring 2
87 80-73-868 Strap, Braided Scotch 2
124 13-05-393 Nut, Lock Cad Plt. ½”-13 4
165 96-10-030 Skid 414 Centrifuge 1
166 96-10-034 Guard, Belt, Feed Tube End 1
167 96-10-035 Guard, Belt, Backdrive End 1
168 96-10-379 Guard, Gearbox 1
169 05-30-117 Bushing 1-3/8” Bore 1
170 05-79-096 Sheave 1
171 31-05-265 Coupling, Drive, Turbostart 1
172 96-10-414 Step Sheave, Motor (4-3V-10.6/4-3V.80) 1
173 96-10-394 Motor Mount Base 25 Hp 1
174 96-10-395 Motor Mount Base 7-1/2 Hp 1
175 50-30-089 Ell, Galv., 2” NPT x 1-1/2” NPT 1
176 96-10-104 Bracket, Limit Switch 1
177 12-20-061 Stud, ¾” x 10 NC x 5-1/2” GR. 8 1
178 13-05-015 Nut, Hex Blk. ¾” x 10 NC 2 H 8
179 58-59-347 Mount, Shock 4
180 58-95-175 Washer, Head 4-1/4” O.D. 4
181 58-95-176 Washer, Tail 3” O.D. 4
182 05-06-114 Belt, 3V-850 Main Drive 4
183 05-06-126 Belt, 3V-1000 Backdrive 2
184 05-06-119 Belt, 3V-900 Main Drive 4
185 96-10-429 Feed Tube, Standard 1
186 96-50-350 Decal Warning, Shipping 2
187 84-20-207 Decal Swaco 3
188 96-50-345 Decal (Caution), Belt Guards 2
189 96-50-363 Decal Wiring Hookup 414/518 1
190 96-50-361 Decal Sheave Speed Change 1
191 96-50-344 Decal (Caution), On Cover 1
192 13-45-092 Washer, Flat Cad. Plt. 5/8”
193 13-45-088 Washer, Flat Cad Plt. 3/8” 56
194 13-45-090 Washer, Flat Cad Plt. ½” 4
195 13-45-087 Washer, Flat Cad Plt. 5/16” 2
196 13-45-086 Washer, Flat Cad Plt. ¼” 2
197 13-45-389 Washer, Lock Cad Plt. ¼” 6
198 13-45-212 Washer, Lock Cad Plt. 3/8” 10
199 13-05-571 Nut, Hex Cad Plt. ¼”-20 2
200 13-05-391 Nut, Lock Cad Plt. 3/8”-16 30
Diagram 1 (414 Centrifuge Parts List)
