55
Index
No.
Swaco
Part No.
Description Qty.
93 84-01-970 SHCS, BLK, M8 x 20 mm 5
94 96-10-430 Washer 1
95 96-10-357 Driver 1
96 96-10-140 Coupling Assy. 1
97 84-01-884 Spring Disc 11
98 84-01-891 Washer 7/8 x 1-11/64 1*
99 96-10-334 Clamp Ring Driver Brass Back Drive Cent 1
100 96-10-408 Screw 3
101 84-01-428 Snap Ring 1
102 84-01-036 Ball Bearing 2
103 96-10-369 Ring Spacer 1
104 96-10-415 Sheave 1
105 96-10-365 Adapter Sheave 1
106 84-01-369 Pin 1
107 96-10-130 Gearbox 1
108 84-01-485 SHCS, SS, M8 x 30 mm 4
* Refer to Section 3.6.3 for quantity used.
Diagram 5 (414 Centrifuge G.S. Coupling 350 KPM Gearbox Parts List)
