Mi Swaco 414 - Page 61

57
Index
No.
Swaco
Part No.
Description Qty.
8 84-01-520 SHCS, BLK., M12 x 90 mm 8
9 96-10-431 Washer Spacer 8
11 28-40-015 Grease Fitting 1
12 96-10-145 Bearing Housing 1
73 96-10-304 Frame 1
78 96-10-144 Bearing Housing 1
110 96-10-384 Conical Pin 2
111 84-01-292 Nut Hex Plt. M12 2
112 84-01-466 SHCS, PLT., M16 x 65 mm 4
113 84-01-872 Clamping Washer 1
114 96-10-312 Welded Bracket 1
115 14-07-529 SHCS, SS, 1/2-13 NC x 2-3/4 4
163 84-01-447 SHCS, SS, M10 x 30 mm 6
164 96-10-383 Pin 2
Diagram 6 (414 Centrifuge Frame Parts List)
