M‑I SWACO MONGOOSE PRO Shale Shaker
55 Field Installation and Operation Manual 9092F02001AENG (D) 55
20.1.2.2 Swing Weights
NOTE
ALWAYS ORDER A COMPLETE MOTOR KIT WHEN BUYING A REPLACEMENT
MOTOR. ORDER THE MOTOR KIT THAT CORRESPONDS TO THE APPROPRIATE
VOLTAGE OF THE MOTOR IT IS REPLACING. REFER TO TABLE 10 FOR A
COMPLETE PARTS BREAKDOWN OF THE MONGOOSE PRO SWING WEIGHT
MOTOR KITS.
Figure 41. MONGOOSE PRO Motor Kit, Swing Weight
Table 10. Swing Weight Motor Kit Parts List*
ITEM
NUMBER
PART
NUMBER
USED IN
MOTOR KIT
NUMBER
DESCRIPTION
QTY.
1
9870528
MOTOR 2.5 HP 220-240/440-480V, SWING WEIGHT
1
9870529
MOTOR 2.5 HP 220-240/380-415V, SWING WEIGHT
9870530
MOTOR 2.5 HP 575-600V, SWING WEIGHT
2
LOCKWASHER NO LONGER USED
0
3
1345015
ALL
WASHER FLAT BLACKENED F436 ¾” X 1-15/32” OD HARDENED
12
4
103057232
ALL
HHCS M20-1.5 X 90 LG METRIC GR 10.9 XYLAN COATING
6
5
103057261
ALL
NUT HEX PLT M20-1.5 GRADE 10.9 XYLAN COATING,
OVERTAP
6
*When replacing a motor, a motor kit MUST be selected
