Michell Instruments MDM25 - Appendix A Technical Specifi Cations

MDM25 User’s Manual
14 97234 Issue 4, January 2018
APPENDIX A
Appendix A Technical Specifi cations
HYGROMETER
Performance
Measurement Units %RH, ºC / ºF Ta, ºC / ºF Td, g/m
3
, ºC / ºF Tw
Mechanical Specifi cation
Ingress Protection IP54
Hygrometer Housing Material Molded polymer housing ABS + rubber surround
Weight 300g (10.58oz)
Display Resolution Graphic LCD 128 x 64 pixels
Electrical Output/Input
Supply Voltage
4.5 V
(3 x ‘AA’ batteries - provide approximately 150 hours of operation)
Electrical Connections M9 5-way binder connector
PROBES
Performance
Measurement Range (RH) 0 - 100% RH
Accuracy at 25ºC (77ºF)
Temperature
±0.2ºC (±0.36ºF)
Stability - RH Sensor ±1% RH/year
Response time - RH Sensor <10 sec typical (for 90% of the step change)
Measurement & Operating
Range (T)
- Fixed and Standard Probe
- Sword Probe
- Remote Probe
-20 to +80ºC (-4 to +176ºF)
-20 to +100ºC (-4 to +212ºF)
-20 to +150ºC (-4 to +302ºF)
Accuracy at 25ºC (77ºF)
Humidity
- Fixed Probe
- Remote Probe
±2% RH (10 - 90% RH)
±2% RH (5 - 95% RH)
Mechanical Specifi cation
Weight
Fixed Probe
Standard Probe
Sword Probe
High Temp 300mm Probe
High Temp 500mm Probe
FPR
SPR
SWPR
HTPR300
HTPR500
30g (1.06 oz)
90g (3.17 oz)
500g (1.1 lb)
380g (13.4 oz)
620g (1.37 lb)
