Unclassified
General Description
1-6
Reception frequency range 100 kHz to 30 MHz
Sensitivity (SINAD)
0.3 V for 10 dB SINAD
Audio bandwidth 350 to 2700 Hz
Data bandwidth 300 to 3300 Hz
Frequency stability 0.6 ppm (0.1 ppm optional)
Frequency resolution 10 Hz
Number of accessories
connectors
4 (see Table 1-1)
Operating voltage 110 /220 VAC, 50/60 Hz, with
automatic switching
Power requirements Max. 2000W
Operating temperature range -10C to +60C/14F to
+140F
Humidity Up to 95% relative humidity
@ 50C/122F
Dimensions
Height 290 mm/11.42 inch
Width 480 mm/18.9 inch
Depth 550 mm/21.7 inch
Weight 32 kg/70.6 lbs
1.6.2 CONNECTOR DATA
1.6.2.1 Accessories Connectors
The functions of the pins in the 25-pin accessories connectors, ACC-J1 to ACC-J4, are
listed in Table 1. The connectors include PTT and CW control lines, audio and baseband
lines for external equipment, auxiliary power output, serial RS-232 asynchronous data
interfaces, and additional dedicated handshaking and control lines. The functions
supported by the serial data interfaces are determined by the RM500/RM500R software.
