Unclassified
Installation Procedure
3-6
a. Identify the installation position of the PPS in the rack, and the position of the
RM500/RM500R to which it will be connected.
b. Install the PPS in the prescribed installation position, fastening it by means of four
screws to the rack rails or to the drawer front.
c. Connect a grounding strap from the PPS unit grounding screw to the prescribed
cabinet’s grounding bar.
d. Set the power switches on the RM500/RM500R and PPS front panels to OFF (down
position).
e. Connect the PPS AC power cable to the prescribed outlet on the power distribution
box of the cabinet.
f. Refer to Figure 5 and connect cables between RM500/RM500R and the PPS as
follows:
RM500/RM500R
Connector
PPS Connector
PPS CONTROL SERIAL I/O
RX IN ANTENNA
TX IN EXEC OUT
TX OUT PA IN
RX OUT RADIO
This completes the installation of the PPS.
