Micro Audiometrics ES3 - Headset Connector; DPU-414 Printer Switch Settings

34
Headset Connector
15-pin high density D-Sub (pin configuration is shown as viewed from top of
instrument)
Pin Function Pin Function
1
+5 V Out
9
Not Used
2 Lt Phn+ 10
Not Used
3 Lt Phn- 11
Ground
5 4 3 2 1
4 Rt Phn+ 12
Not Used
10 9 8 7 6
5 Rt Phn- 13
Not Used
15 14 13 12 11
6
RspButton
14
Not Used
7
Ground
15
Not Used
8
Not Used
DPU-414 Printer Switch Settings
The setup switches on the Seiko Instruments DPU-414 printer should be set as
follows to ensure compatibility with Micro Audiometrics ES3 audiometers.
SW1 - 1 - OFF SW2 - 1 - ON SW3 - 1 - ON
2 – ON 2 - ON 2 – ON
3 – ON 3 - ON 3 – ON
4 – ON 4 – ON 4 – OFF
5 – ON 5 – ON 5 – OFF
6 – OFF 6 – ON 6 – ON
7 – ON 7 – ON 7 – ON
8 – ON 8 – OFF 8 - ON
