MICRO-EPSILON TIM 160 - Vibration; Shock; Used Standards; Stress Program (Camera in Operation)

Page 14
Technical Data
thermoIMAGER TIM
2.4 Vibration / Shock
2.4.1 Used Standards
IEC EN 60068-1: 1995-03 Environmental testing - Part 1: General and guidance
IEC 60068-2-6: 2008-10 Environmental testing - Part 2-6: Tests - Test Fc: Vibration
(sinusoidal)
IEC 60068-2-27: 2010-02 Environmental testing - Part 2-27: Test Ea and guidance:
Shock
IEC 60068-2-47: 2006-03 Environmental testing - Part 2-47: Mounting of specimens
for vibration, impact and similar dynamic tests
IEC 60068-2-64: 2009-04 Environmental testing - Part 2-64: Tests -
Tests Fh: Vibration, broadband random and guidance
2.4.2 Stress Program (Camera in Operation)
Shock, half sinus 25 g – testing Ea 25 g (acc. IEC 60068-2-27)
Acceleration 245 m/s
2
(25 g)
Pulse duration 11 ms
Number of directions 6 (3 axes with 2 directions each)
Duration 600 shocks (100 shocks each direction)
Shock, half sinus 50 g – testing Ea 50 g (acc. IEC 60068-2-27)
Acceleration 490 m/s
2
(50 g)
Pulse duration 11 ms
Number of directions 6 (3 axes with 2 directions each)
Duration 18 shocks (3 shocks each direction)
