2.7 Microscope Lenses
Model TIM 450 TIM 640
Optical resolution 382 x 288 Pixel @ 80 Hz 640 x 480 Pixel @ 32 Hz
640 x 120 Pixel @ 125 Hz
Temperature ranges (scalable) -20 to 100°C, 0 to 250 °C, (20)150 to 900 °C
1)
Spectral range 7.5 to 13 μm
Frame rate 80 Hz (switchable to 27 Hz) 125 Hz (switchable to 32 Hz)
System accuracy ± 2 °C or ± 2 %, whichever is greater
Microscope lens (FOV) 10° x 8° (F = 1.1) / f = 44 mm 12° x 9° (F = 1.1) / f = 44 mm
Smallest spot size (IFOV) 42 μm 28 μm
MFOV 85 μm
2)
Focus adjustment 80 to 100 mm
Thermal sensitivity (NETD) 90 mK 120 mK
Detector FPA – uncooled micro bolometer
Outputs/digital USB 2.0
Standard process interface (PIF) 0 - 10 V input, digital input (max. 24 V), 0 - 10 V output
Industry process interface (IPIF) 2 x 0 -10 V input, digital input (max. 24 V), 3 x 0 -10 V output,
3 x Relais (0 - 30 V / 400 mA), fail-safe relay
Cable length (USB) 1 m (standard), 3 m, 5 m, 10 m, 20 m
Power supply USB powered
Tripod mount ¼-20 UNC
Protection class IP 67
Ambient temperature range 0 °C to 70 °C 0 °C to 50 °C
Storage temperature -40 °C to 70 °C
Relative humidity 20 to 80 %, non-condensing
