4.25.x Enter DATA within the following range
(0-255)
Enter valid data into the TEXT field. The tool is expecting a
decimal value in the range of “0-255”.
4.30.x Enter a valid PERIOD within the following
range (100-5000)\nOr (0) for a one-shot
message
Enter a valid period into the TEXT field. The tool is expecting
a decimal value in the range of “0 or 100-5000”.
4.40.x Enter a valid REPEAT within the following
range (1-99)\nOr (0) for a one-shot
message
Enter a valid repeat into the TEXT field. The tool is expecting
a decimal value in the range of “0-99”.
4.70.x Unknown error caused by user input Check that the TEXT field only has no special characters or
spaces.
4.75.x Required input for CAN Message is empty Check that the ID, DLC, DATA, PERIOD and REPEAT fields
contain valid data.
5.00.x Reserved for Message Received errors Reserved for Message Received errors.
6.00.x Unable to Log Data Tool is unable to write CAN traffic to Log File. Possible cause
may be that the drive is either full, write-protected or does not
exist.
TABLE A-1: ERROR MESSAGES (CONTINUED)
Error
Number
Error Possible Solution
