Design Details
2020 Microchip Technology Inc. DS50002927A-page 65
FIGURE C-7: +3.3V POWER SUPPLY
V
IN
V
OUT
+5V
C100
10 µF
C101
10 µF
C102
0.1 µF
C103
0.1 µF
C104
10 µF
C105
10 µF
C106
0.1 µF
V
IN
V
OUT
GND
U12
MCP1826S/3.3V
13
2
DGND
R19
0R
0805
AGND
+3.3V +3.3 VA
R15
0R
0805
