AN3118
3.0 AUDIO TRANSCEIVER
SOLUTION
Microchip's Audio Transceiver (AT) solution enables
Bluetooth capability in non-Bluetooth Audio-
equipment. The AT receives audio inputs through Aux-
in or I
2
S pin and streams the audio up to two Bluetooth
paired sink devices.
The AT solution can work as either an A2DP source or
A2DP/HFP sink (where BM83 is a sink device).
The following figure illustrates a typical example of an
audio transmitter taking input from Aux-in and
transmitting the signal to two connected sink devices.
FIGURE 29: AUDIO TRANSMITTER WITH AUX-IN AS AUDIO INPUT
The following figure illustrates a typical example of
audio transmitter taking I
2
S as input and transmitting to
two connected sink devices.
FIGURE 30: AUDIO TRANSMITTER WITH I
2
S AS AUDIO INPUT
Note: HFP source is not supported in the current
Microchip Audio Transceiver solution.
Aux-in
Connection
IS2083BM
Audio Tx
(Source)
Peripheral
Speaker
(Sink)
Peripheral
Speaker
(Sink)
Slave
Speaker
(Sink)
Slave
Speaker
(Sink)
I2S
Connection
IS2083BM
Audio Tx
(Source)
EXT AMP
Peripheral
Speaker
(Sink)
Peripheral
Speaker
(Sink)
I2S
Connection
IS2083BM
Audio Tx
(Source)
EXT AMP
