2021 Microchip Technology Inc. DS00003118C-Page 15
AN3118
6. The “Concert Master” is assigned to a BM83 EVB, see Figure 12.
FIGURE 12: STATUS CONCERT CENTRAL
7. From the app, click Concert Master device, then Audio. Next, select Pairing Mode Enter to enter Pairing mode
(see Figure 13). Select Speaker Connection Connect and a list of discoverable Bluetooth devices will be dis-
played on the Android phone; select the device with the name MCHP_Multi_x to pair and connect. Now the con-
cert central device audio is connected.
FIGURE 13: AUDIO CONNECTION
