2021 Microchip Technology Inc. DS00003118C-Page 6
AN3118
FIGURE 4: STEREO MODE: CENTRAL IS CONNECTED TO BLUETOOTH-ENABLED DEVICE
Figure 5 illustrates a typical Stereo mode application
where the central is connected to a Bluetooth-enabled
device through AUX-In.
FIGURE 5: STEREO MODE: CENTRAL IS CONNECTED TO BLUETOOTH-ENABLED DEVICE
THROUGH AUX-IN
IS2083BM
Central
Speaker
IS2083BM
Peripheral
Speaker
Smartphone or Tablet
Alternative Audio
Source
(Amplifier, Sound bar,
Stereo etc.)
Smartphone/Tablet
Aux-in
Connection
IS2083BM
Central
Speaker
IS2083BM
Peripheral
Speaker
OR
