12. PROGRAMMING
The relay is supplied with the standard default programming used for factory test. [ Values here below
reported in the “ Display “ column ].
All parameters can be modified as needed in the mode PROG and displayed in the mode SET DISP
Local Programming by the front face key board is enabled only if no input current is detected
(main switch open). Programming via the serial port is always enabled but a password is
required to access the programming mode. The default password is the null string; in the
standard application program for communication “MS-COM” it is also provided an emergency
password which can be disclosed on request only.
As soon as programming is enabled, the Led PRG/IRF flashes and the reclosing lock-out relay R5 is
deenergized. Enter MODE "PROG" and SELECT either "SETTINGS" for programming of parameters
or "FRELAY" for programming of output relays configuration; enable programming by the indirect
operation key PROG.
The key SELECT now scrolls the available parameters. By the key (+) , (-) the displayed values can be
modified; to speed up parameter's variation press the key SELECT while "+" or "-" are pressed.
Press key "ENTER/RESET" to validate the set values.
12.1 - PROGRAMMING OF FUNCTIONS SETTINGS
Mode PROG menu SETTINGS. (Production standard settings here under shown).
Display
Description
Setting Range
Step
Unit
xxXXXxx
Current date
DDMMMYY
-
-
xx:xx:xx
Current time
HH:MM:SS
-
-
NodAd 1
Identification number for connection on serial communication bus
1 - 250
1
1
Fn 50 Hz
Mains frequency
50 - 60
10
Hz
In 500Ap
Rated primary current of the phase C.Ts.
1 - 9999
1
Ap
On 500Ap
Rated primary current of the C.Ts. or of the tore C.T. detecting
earth fault current
1 - 9999
1
Ap
Im 1.0In
Motor full-load current
(p.u. of phase C.Ts. rated current)
0.1 – 1.5
0.01
In
Ist 6Im
Motor start-up current (p.u. of motor full load current)
0.5 – 10
0.1
Im
tst 5s
Motor starting time
1 – 120
1
s
ITr0.5Ist
Switch-over current of motor starter
(p.u. of motor starting current)
Dis – 0.1 – 1
0.1
Ist
tTr 6s
Max switch-over time from reduced to full voltage operation
during motor starting.
0.5 – 50
0.1
s
In 500 Ap
Ap is the unit of measure,
Amps primary.
500 is the
setting default
In is the name
of the variable
