15. ELECTRICAL CHARACTERISTICS
APPROVAL: CE – RINA – UL and CSA approval File : E202083
REFERENCE STANDARDS IEC 60255 - EN50263 - CE Directive - EN/IEC61000 - IEEE C37

Dielectric test voltage
IEC 60255-5
2kV, 50/60Hz, 1 min.

Impulse test voltage
IEC 60255-5 : 5kV (c.m.), 2 kV (d.m.) - 1,2/50s
5kV (c.m.), 2kV (d.m.) – 1,2/50s

Insulation resistance
> 100M
Environmental Std. Ref. (IEC 68-2-1 - 68-2-2 - 68-2-33)

Operation ambient temperature
-10°C / +55°C

Storage temperature
-25°C / +70°C

Humidity
IEC68-2-3 RH 93% Without Condensing AT 40°C
CE EMC Compatibility (EN50081-2 - EN50082-2 - EN50263)

Electromagnetic emission
EN55022 industrial environment

Radiated electromagnetic field immunity test
IEC61000-4-3
level 3
80-1000MHz
10V/m
ENV50204
900MHz/200Hz
10V/m

Conducted disturbances immunity test
IEC61000-4-6
level 3
0.15-80MHz
10V

Electrostatic discharge test
IEC61000-4-2
level 4
6kV contact / 8kV air

Power frequency magnetic test
IEC61000-4-8
1000A/m
50/60Hz

Pulse magnetic field
IEC61000-4-9
1000A/m, 8/20s

Damped oscillatory magnetic field
IEC61000-4-10
100A/m, 0.1-1MHz

Electrical fast transient/burst
IEC61000-4-4
level 3
2kV, 5kHz

HF disturbance test with damped oscillatory wave (1MHz
burst test)
IEC60255-22-1
class 3
400pps, 2,5kV (m.c.), 1kV (d.m.)

Oscillatory waves (Ring waves)
IEC61000-4-12
level 4
4kV(c.m.), 2kV(d.m.)

Surge immunity test
IEC61000-4-5
level 4
2kV(c.m.), 1kV(d.m.)

Voltage interruptions
IEC60255-4-11

Resistance to vibration and shocks
IEC60255-21-1 - IEC60255-21-2 10-500Hz 1g

Accuracy at reference value of influencing factors
2% In
for measure
0,2% On
2% +/- 10ms
for times

Rated Current
In = 1 or 5A - On = 1 or 5A

Current overload
200 A for 1 sec; 10A continuous

Burden on current inputs
Phase : 0.01VA at In = 1A; 0.2VA at In = 5A
Neutral : 0.015VA at On = 1A; 0.4VA at On = 5A

Rated Voltage
Un = 100V (different on request)

Overload overload
2 Un permanent

Burden on voltage inputs
0.04 VA at Un

Average power supply consumption
8.5 VA

Output relays
rating 5 A; Vn = 380 V
A.C. resistive switching = 1100W (380V max)
make = 30 A (peak) 0,5 sec.
break = 0.3 A, 110 Vcc,
L/R = 40 ms (100.000 op.)
