BRAND: Alliance
TYPE: HD-73
38
Rotator connection to 10 pin ROTATOR (9) terminal:
ROTATOR ARCO
WIRE PIN NAME PIN
CW 1 MOTOR A 6
WIPER 2 SENSOR C 2
COM 3 MOTOR D 5
POT LO 4 SENSOR LO 1
POT HI 5 SENSOR HI 3
CCW 6 MOTOR C 4
Rotator tab settings:
PARAMETER VALUE
SENSOR POT 75 Ω
MOTOR AC
POWER 24 V
BRAKE NO
TOTAL ROTATION 360
LIMIT SWITCHES NO
