ACCESSORY - DB25
Pin # Label Description
1 NC N/A
14 NC N/A
2 PIN2 Configurable I/O, TTL levels, max 4mA load, RX DATA Serial 2
15 +5 5V output, max. 100mA load
3 PIN3 Configurable I/O, TTL levels, max 4mA load, TX DATA Serial 2
16 NC N/A
4 PIN4 Configurable I/O, TTL levels, max 4mA load, TX DATA Serial 1
17 NC N/A
5 PIN5 Configurable I/O, TTL levels, max 4mA load, RX DATA Serial 1
18 GND GND
6 PIN6 Configurable I/O, TTL levels, max 4mA load
19 GND GND
7 PIN7 Configurable I/O, TTL levels, max 4mA load
20 GND GND
8 PIN8 Configurable I/O, TTL levels, max 4mA load
21 GND GND
9 PIN9 Configurable I/O, TTL levels, max 4mA load
22 GND GND
10 PIN10 Configurable I/O, TTL levels, max 4mA load
23 GND GND
11 PIN11 Configurable I/O, TTL levels, max 4mA load
24 GND GND
12 PIN12 Configurable I/O, TTL levels, max 4mA load
25 GND GND
13 PIN13 Configurable I/O, TTL levels, max 4mA load
SHELL GND GND
