microHAM © 2010 All rights reserved
iLINK – miniDIN 6
Pin # Label Description
1 DATA I2C Data channel for expansion (TTL)
2 n/c Not connected
3 GND Connected to system ground and case
4 +5 V +5V output, max.100mA.
5 CLOCK I2C Data Clock (TTL)
6 n/c Reserved – do not use
SHELL GND Connected to system ground and case
PAD – miniDIN 6
Pin # Label Description
1 PS/2 DATA TTL PS/2 DATA line
2 n/c WinKey 2 Command
3 GND Connected to the system ground and case.
4 +5 V +5V output, max.100mA.
5 PS/2 Clock TTL PS/2 CLOCK line
6 n/c PAD Interrupt
SHELL GND Connected to system ground and case
PS/2 – miniDIN 6
Pin # Label Description
1 PS/2 DATA TTL PS/2 DATA line
2 n/c Not connected
3 GND Connected to the system ground and case.
4 +5 V +5V output, max.100mA.
5 PS/2 Clock TTL PS/2 CLOCK line
6 n/c Not connected
SHELL GND Connected to system ground and case
84
