1.0 Overview
1.3 Performance Specifications
MIMO (2X2) ON
Modulation IPerf Throughput
(Mbps)
Throughput @
Sensitivity (dBm)
Maximum Total Tx
Power (dBm) +/- 1dB
8 MHz Channel Bandwidth
BPSK_1/2 3 -99.5 30dBm
QPSK_1/2 5.9 -98 30dBm
QPSK_3/4 8.8 -96 30dBm
16QAM_1/2 11.6 -92 30dBm
16QAM_3/4 17.1 -90 30dBm
64QAM_2/3 22.8 -85 30dBm
64QAM_3/4 25.5 -83.5 30dBm
64QAM_5/6 27.8 -81 30dBm
4 MHz Channel Bandwidth
BPSK_1/2 1.51 -102.5 30dBm
QPSK_1/2 2.98 -101 30dBm
QPSK_3/4 4.4 -99 30dBm
16QAM_1/2 5.8 -95.5 30dBm
16QAM_3/4 8.6 -93 30dBm
64QAM_2/3 11.4 -88 30dBm
64QAM_3/4 12.8 -86 30dBm
64QAM_5/6 14 -83.5 30dBm
Table 1-2: pMDDL Performance Specifications
MIMO OFF
Modulation IPerf Throughput
(Mbps)
Throughput @
Sensitivity (dBm)
Maximum Tx
Power (dBm) +/- 1dB
8 MHz Channel Bandwidth
BPSK_1/2 3 -96.5 30dBm
QPSK_1/2 5.8 -95 30dBm
QPSK_3/4 8.6 -93 30dBm
16QAM_1/2 11.5 -89 30dBm
16QAM_3/4 16.9 -87 30dBm
64QAM_2/3 22.2 -82 28dBm
64QAM_3/4 24.7 -80.5 28dBm
64QAM_5/6 27.4 -78 27dBm
4 MHz Channel Bandwidth
BPSK_1/2 1.5 -99.5 30dBm
QPSK_1/2 2.9 -98 30dBm
QPSK_3/4 4.3 -96 30dBm
16QAM_1/2 5.7 -92.5 30dBm
16QAM_3/4 8.4 -90 30dBm
64QAM_2/3 11.3 -85 28dBm
64QAM_3/4 12.5 -83 28dBm
64QAM_5/6 14 -80.5 27dBm
